The Digi-S281 is a compact Bluetooth digital pressure gauge with a modern, almost square design. Unlike classic round digital pressure gauges, this model features a large, easy-to-read LCD display with big digits and backlight.
With an accuracy of 0.2 % FS, this device is suitable for precise pressure measurements in maintenance, service, workshops, test engineering and industrial applications. In addition, the Digi-S281 offers a MIN/MAX display, various selectable pressure units and a 330° rotatable housing so that the display can be ideally aligned after installation.
A particularly interesting feature is the Bluetooth function: In combination with our SECA Bluetooth app, measured values can be displayed live, shown graphically and documented. This also makes the Digi-S281 suitable for simple measurement reports and mobile inspections.
Important note: The measured data is not stored inside the device itself. Recording is only possible with an active Bluetooth connection to the app. If you are looking for a pressure gauge with reliable internal data storage directly inside the device, we recommend our Digi-Log.
Thanks to its robust housing, battery operation with 2 x AA batteries and suitability for oil, water, gas and other non-corrosive media, the Digi-S281 is a versatile digital pressure gauge for a wide range of pressure measurement tasks.
| Technical Details |
Specification |
| Device type |
Bluetooth digital pressure gauge |
| Model |
Digi-S281 |
| Accuracy |
0.2 % FS |
| Display |
Large LCD display with backlight |
| Functions |
Bluetooth, MIN/MAX display, zero reset, unit switching, backlight |
| Data recording |
Via Bluetooth connection in the app, no internal data storage in the device |
| Rotation |
330° |
| Power supply |
3 V via 2 x AA batteries |
| Protection class |
IP54 |
| Operating temperature |
-20 to +65 °C |
| Measuring media |
Oil, water, gas and other non-corrosive media |
| Connection |
Standard G1/4", other connections depending on version or on request |
| Materials |
Housing made of TPE+ABS, connection material 304, measuring cell 316L |
| Pressure units |
MPa, bar, kgf, mH2O, PSI, kPa, mmHg, mbar, mmH2O, Pa, inWC |
| Dimensions |
143.5 x 75 x 40.5 mm |
| Pressure ranges |
Various pressure ranges available, depending on version |
|
Our SECA Bluetooth app:
Real-time measurement, switch sensor units, Excel export.
Free: Interactive Excel Dashboard
Get more out of your Digi-Log measurements.
Our new analysis tool creates dynamic charts and precise test reports at the touch of a button.
Simply import the CSV file, filter the time period and view the results instantly.
Digi-Log Analysis Tool v1.0
|
|
| Item information |
Value |
| Shipping weight: |
0,35 kg
|
| Item weight: |
0,25 kg
|
